ABSOLUTE Digimatic Height Gauge – Series 570 – with ABSOLUTE Linear Encoder

Starting at $581.40

Built in ABSOLUTE linear encoder.
This encoder eliminates the necessity of setting the reference point at every power-on. It has improved reliability because no over-speed error will occur.
Rigid column structure ensures high measuring accuracy.
With large smooth slider feed wheel.
Carbide-tipped scriber is provided.
With SPC data output.

Clear
Qty:
SKU: N/A Category:

Description

SKUItem TypeRangeAccuracyLCD ResolutionPriceBuyhf:att:pa_item-typehf:att:pa_color
570-312Inch/Metric0-12in 0-300mm.0015in.0005in 0.01mm$581.40
Qty:
inch-metric
570-313Inch/Metric0-18in 0-450mm.002in.0005in 0.01mm$815.40
Qty:
inch-metric
570-314Inch/Metric0-24in 0-600mm.002in.0005in 0.01mm$1,044.00
Qty:
inch-metric
570-302Metric0-300mm0.03mm0.01mm$581.40
Qty:
metric
570-304Metric0-600mm0.05mm0.01mm$1,044.00
Qty:
metric

Optional Accessories

SKUDescriptionPriceBuyhf:att:pa_colorhf:att:pa_item-type
953638Holding Bar for test indicator (50mm)$12.11
Qty:
902053Swivel Clamp used w/ Holding Bar (Metric)$17.69
Qty:
900322Swivel Clamp used w/ Holding Bar (Inch)$19.80
Qty:
953639Holding Bar for test indicator (2")$14.09
Qty:
905338SPC cable (40"/1m)$36.05
Qty:
905409SPC cable (80"/2m)$42.98
Qty:

Features

Built in ABSOLUTE linear encoder.
This encoder eliminates the necessity of setting the reference point at every power-on. It has improved reliability because no over-speed error will occur.
Rigid column structure ensures high measuring accuracy.
With large smooth slider feed wheel.
Carbide-tipped scriber is provided.
With SPC data output.

Technical Data

Resolution: 0.01mm or .0005″/0.01mm
Display: LCD, 6-digit
Length standard: ABSOLUTE electrostatic capacitance type linear encoder
Max. response speed: Un limited
Battery: SR44 (1 pc.), 938882
Battery life: Approx. 20000 hours under normal use

Function

Origin setting, ABS/INC switching,
Power ON/OFF, Data hold, Data output, inch/mm conversion (inch/mm models)
Alarm: Low voltage, Counting value composition error

Standard Scriber Provided

Metric models: Carbide-tipped scriber (07GZA000), scriber clamp (05GZA033)
Inch/Metric models: Carbide-tipped scriber

Optional Accessories

905338: SPC cable (40” / 1m)
905409: SPC cable (80” / 2m)
953638: Holding bar for test indicator (length: 50mm)
953639: Holding bar for test indicator (length: 2”)
902053: Swivel clamp used with holding bar (metric)
900322: Swivel clamp used with holding bar (inch)

Additional information

Weight N/A
Dimensions N/A
Item Type

Inch/Metric, Metric

Range

0-12in 0-300mm, 0-18in 0-450mm, 0-24in 0-600mm, 0-300mm, 0-600mm

Accuracy

.0015in, .002in, 0.03mm, 0.05mm

LCD Resolution

.0005in 0.01mm, 0.01mm
