Uni-Mike – Series 317, 117 – Interchangeable Anvil Type

Starting at $192.60

IP65 water/dust protection (Series 317)
Measures tubing thickness, shoulderedge distance, rivet head height, etc. with interchangeable anvils (flat anvil, rod anvil,V-anvil).
Supplied with Flat Anvil (201216) and Rod Anvil:
ø3mm/.118” rod anvil (201217) for 0-25mm/0-1” models, ø5mm/.197” (201379) for 25-50mm / 1-2” model.
With special Disk Anvils. The Uni-Mike is used as a height micrometer.The disks have a lapped, mirror surface.
With a standard bar except
0-25mm and 0 -1” model.
Supplied in fitted plastic case.

Clear
Qty:
SKU: N/A Category:

Description

SKUItem TypeRangeAccuracyRemarksMassPriceBuyhf:att:pa_item-typehf:att:pa_color
117-107Inch0-1in±.0002inWith friction thimble255g$192.60
Qty:
inch
117-108Inch1-2in±.0002inWith friction thimble320g$225.90
Qty:
inch
317-351-30Inch/Metric0-1in 0-25.4±4µmDigital model with friction thimble340g$490.50
Qty:
inch-metric
317-352-30Inch/Metric1-2in 25.4-50.8±4µmDigital model with friction thimble365g$498.60
Qty:
inch-metric
117-101Metric0-25mm±4µmWith ratchet stop255g$192.60
Qty:
metric
117-102Metric25-50mm±4µmWith ratchet stop320g$225.90
Qty:
metric
317-251-30Metric0-25mm±.0002inDigital model with ratchet stop335g$490.50
Qty:
metric
317-252-30Metric25-50mm±.0002inDigital model with ratchet stop360g$498.60
Qty:
metric

Optional Accessories

SKUDescriptionPriceBuy
201218V-anvil$14.00
Qty:
950758Disk anvil for 25m (1") models"$80.51
Qty:
05CZA662SPC cable with data switch (40in / 1m)$75.42
Qty:
05CZA663SPC cable with data switch (80in / 2m)$83.21
Qty:

Features

IP65 water/dust protection (Series 317)
Measures tubing thickness, shoulderedge distance, rivet head height, etc. with interchangeable anvils (flat anvil, rod anvil,V-anvil).
Supplied with Flat Anvil (201216) and Rod Anvil:
ø3mm/.118” rod anvil (201217) for 0-25mm/0-1” models, ø5mm/.197” (201379) for 25-50mm / 1-2” model.
With special Disk Anvils. The Uni-Mike is used as a height micrometer.The disks have a lapped, mirror surface.
With a standard bar except
0-25mm and 0 -1” model.
Supplied in fitted plastic case.

Technical Data

Accuracy: Refer to the list of specifications.
Resolution*: 0.001mm or .00005″/0.001mm
Graduation**: 0.01mm or .0001″
Spindle face: Carbide tipped
Display*: LCD
Battery*: SR44 (1 pc.), 938882
Battery life*: Approx. 1.2 years under normal use
Dust/Water protection level*: IP65
*Digital models **Analog models

Function of Digital Model

Origin-set, Zero-setting, Data hold, Data output, inch/mm conversion (inch/mm models)
Alarm: Low voltage, Counting value composition error

Optional Accessories

05CZA662: SPC cable with data switch (1m/40”)*
05CZA663: SPC cable with data switch (2m/80”)*
201218: V-anvil
950758: Disk anvil for 25m (1″) models

Additional information

Weight N/A
Dimensions N/A
Item Type

Inch, Inch/Metric, Metric

Range

0-1in, 1-2in, 0-1in 0-25.4, 1-2in 25.4-50.8, 0-25mm, 25-50mm

Accuracy

±.0002in, ±4µm

Remarks

With friction thimble, With ratchet stop, Digital model with ratchet stop, Digital model with friction thimble

Mass

255g, 320g, 335g, 340g, 360g, 365g
