Outside Micrometers – Series 107

Name: Outside Micrometers - Series 107
SKU: 11606
Availability: InStock

Spline Micrometers - Series 331, 111Outside Micrometers - Series 406 - Non-Rotating Spindle Type

Starting at $419.40

With dial indicator for direct GO/NG-GO judgment for mass-produced parts.
Anvil retracting trigger for quick measurement.
With a standard bar except for 0-25mm model.
Supplied in fitted plastic case.

SKU: N/A Category: Micrometers

Description
Additional information

Description

SKU	Item Type	Range	Accuracy	Price	Buy	hf:att:pa_item-type
107-201	Metric	0-25mm	±2µm	$419.40	Qty:	metric
107-202	Metric	25-50mm	±2µm	$429.30	Qty:	metric
107-203	Metric	50-75mm	±2µm	$513.90	Qty:	metric
107-204	Metric	75-100mm	±3µm	$520.20	Qty:	metric
107-205	Metric	100-125mm	±3µm	$467.10	Qty:	metric
107-206	Metric	125-150mm	±3µm	$486.00	Qty:	metric
107-207	Metric	150-175mm	±4µm	$493.20	Qty:	metric
107-208	Metric	175-200mm	±4µm	$502.20	Qty:	metric

Features

With dial indicator for direct GO/NG-GO judgment for mass-produced parts.
Anvil retracting trigger for quick measurement.
With a standard bar except for 0-25mm model.
Supplied in fitted plastic case.

Technical Data

Graduation: 0.01mm(thimble)
Flatness: 0.6µm
Parallelism: (2+R/100)µm,R=max.range (mm)
Measuring faces: Carbide tipped )

Additional information

Weight	N/A
Dimensions	N/A
Item Type	Metric
Range	0-25mm, 25-50mm, 50-75mm, 75-100mm, 100-125mm, 125-150mm, 150-175mm, 175-200mm
Accuracy	±2µm, ±3µm, ±4µm
