ABSOLUTE Super Caliper – SERIES 500

Starting at $166.50

Mitutoyo’s Absolute Solar Digimatic Caliper retains its origin point even if the display turns off for the entire life of the caliper. At 60 Lux and up the ABSOLUTE solar caliper is, turned on ready to start measurement.
No more repeated zero setting caused by the shortage of light intensity.
Hard-coated solar panel for safe operation.
No fear for overspeed errors.
With thumb roller.
Supplied in fitted plastic case.

Clear
Qty:
SKU: N/A Category:

Description

SKUItem TypeRangeAccuracyLCD ResolutionRemarksPriceBuyhf:att:pa_item-typehf:att:pa_color
500-473Inch/Metric0-4in 0-100mm±.001in.0005in 0.01mm.075" Round Depth Bar without SPC output$166.50
Qty:
inch-metric
500-463Inch/Metric0-4in 0-100mm±.001in.0005in 0.01mm.075in Round Depth Bar with SPC output$240.30
Qty:
inch-metric
500-464Inch/Metric0-6in 0-150mm±.001in.0005in 0.01mmwith SPC output$281.70
Qty:
inch-metric
500-474Inch/Metric0-6in 0-150mm±.001in.0005in 0.01mmwithout SPC output$180.90
Qty:
inch-metric
500-465Inch/Metric0-8in 0-200mm±.001in.0005in 0.01mmwith SPC output$330.30
Qty:
inch-metric
500-475Inch/Metric0-8in 0-200mm±.001in.0005in 0.01mmwithout SPC output$235.80
Qty:
inch-metric
500-443Metric0-100mm±0.02mm0.01mmØ1.9mm round depth bar$240.30
Qty:
metric
500-444Metric0-150mm±0.02mm0.01mm-$281.70
Qty:
metric
500-454Metric0-150mm±0.02mm0.01mmwithout SPC output$175.50
Qty:
metric
500-445Metric0-200mm±0.02mm0.01mm-$330.30
Qty:
metric
500-455Metric0-200mm±0.02mm0.01mmwithout SPC output$235.80
Qty:
metric

Optional Accessories

SKUDescriptionPriceBuyhf:att:pa_colorhf:att:pa_item-type
959143Data hold unit (SPC output model only)$19.49
Qty:
959149SPC cable with data switch (1m / 40”)$44.33
Qty:
959150SPC cable with data switch (2m / 80”)$49.68
Qty:

Features

Mitutoyo’s Absolute Solar Digimatic Caliper retains its origin point even if the display turns off for the entire life of the caliper. At 60 Lux and up the ABSOLUTE solar caliper is, turned on ready to start measurement.
No more repeated zero setting caused by the shortage of light intensity.
Hard-coated solar panel for safe operation.
No fear for overspeed errors.
With thumb roller.
Supplied in fitted plastic case.

Technical Data

Resolution: 0.01mm or .0005″/0.01mm
Repeatability: 0.01mm / .0005”
Display: LCD
Length standard:ABSOLUTE electrostatic capacitance type
linear encoder
Max. response speed: Unlimited
Battery: Solar battery*
*Can be used continuously above 60 lux ambient illumination.

Function

Origin-set, Data hold, Data output, inch/mm conversion
(inch/ mm models)
Alarm: Counting value composition error

Optional Accessories

959143: Data hold unit (SPC output model only)
959149: SPC cable with data switch (1m / 40”)
959150: SPC cable with data switch (2m / 80”)

Additional information

Weight N/A
Dimensions N/A
Item Type

Inch/Metric, Metric

Range

0-4in 0-100mm, 0-6in 0-150mm, 0-8in 0-200mm, 0-100mm, 0-150mm, 0-200mm

Accuracy

±.001in, ±0.02mm

LCD Resolution

.0005in 0.01mm, 0.01mm

Remarks

-, .075in Round Depth Bar with SPC output, .075" Round Depth Bar without SPC output, with SPC output, without SPC output, Ø1.9mm round depth bar
