Description
| SKU | Item Type | Range | Accuracy | LCD Resolution | Remarks | Price | Buy | hf:att:pa_item-type | hf:att:pa_color |
|---|---|---|---|---|---|---|---|---|---|
| 551-311-20 | Inch/Metric | 0(.4)-8in 0(10)-200mm | .001in | .0005in 0.01mm | IP67 | $536.40 | | inch-metric | |
| 551-341-10 | Inch/Metric | 0(.4)-12in 0(10)-300mm | .002in | .0005in 0.01mm | with offset/preset function for easy ID measurement, IP67 | $768.60 | | inch-metric | |
| 551-224-10 | Inch/Metric | 0(.5)-20in 0(20)-500mm | .0025in | .0005in 0.01mm | - | $1,134.00 | | inch-metric | |
| 551-226-10 | Inch/Metric | 0(.5)-30in 0(20)-750mm | .0025in | .0005in 0.01mm | - | $1,836.00 | | inch-metric | |
| 551-227-10 | Inch/Metric | 0(1)-40in 0(20)-1000mm | .003in | .0005in 0.01mm | - | $1,926.00 | | inch-metric | |
| 551-301-10 | Metric | 0(10)-200mm | 0.03mm | 0.01mm | IP67 | $536.40 | | metric | |
| 551-331-10 | Metric | 0(10)-300mm | 0.04mm | 0.01mm | with offset/preset function for easy ID measurement, IP67 | $768.60 | | metric | |
| 551-204-10 | Metric | 0(20)-500mm | 0.06mm | 0.01mm | - | $1,125.00 | | metric | |
| 551-206-10 | Metric | 0(20)-750mm | 0.06mm | 0.01mm | - | $1,836.00 | | metric | |
| 551-207-10 | Metric | 0(20)-1000mm | 0.07mm | 0.01mm | - | $1,926.00 | | metric |
Optional Accessories for Digital Model
| SKU | Description | Price | Buy | hf:att:pa_color | hf:att:pa_item-type |
|---|---|---|---|---|---|
| 05CZA624 | SPC cable with data switch (1m / 40”) | $84.51 | | ||
| 05CZA625 | SPC cable with data switch (2m / 80”) | $85.82 | |
Features
The rounded faces of the jaws are ideal for accurate ID (inside diameter) measurement.
With SPC output.
Supplied in fitted plastic holster in carton.18″/450mm and larger supplied wooden case.
Technical Data
Accuracy: Refer to the list of specifications.
Resolution*: 0.01mm or .0005″/0.01mm
Display*: LCD
Length standard*: ABSOLUTE electrostatic capacitance type linear encoder
Max. response speed*: Unlimited
Battery*: SR44 (1 pc.),938882
Battery life*: Approx. 3.5 years under normal use
Optional Accessories for Digital Model
05CZA624:SPC cable with data switch (1m / 40”)
05CZA625:SPC cable with data switch (2m / 80”)
