Back Plunger Type Dial Indicators – Series 2

Starting at $159.30

Back plunger type dial gauges are suitable for mounting onto leveling machine tool tables or inspection jigs, and for use in small spaces where the graduations of standard dial gauges are difficult to see.
Models 2960T, 2961T, 2990T-10 and 2991T-10, which use Mitutoyo’s proprietary shock-proofing mechanism, have excellent durability and shock resistance.
Model 2990T-10 provides 0.001mm graduation.

Clear
Qty:
SKU: N/A Category:

Description

SKUItem TypeRange / Full StrokeAccuracyGraduationDial ReadingForceRemarksPriceBuyhf:att:pa_item-typehf:att:pa_color
2991T-10Inch.008in/.01in.0002in.0001in4-0-40.4-1.5NOne revolution type / Shockproof / Jeweled bearings$250.20
Qty:
inch
2961TInch.04in/.05in.0005in.0005in20-0-200.4-1.4NOne revolution type / Shockproof$159.30
Qty:
inch
2990T-10Metric0.1mm/0.14mm0.0065mm0.001mm50-0-500.4-1.5NOne revolution type / Shockproof / Jeweled bearings$250.20
Qty:
metric
2960TMetric1mm/1.27mm0.014mm0.01mm50-0-500.4-1.4NOne revolution type / Shockproof$159.30
Qty:
metric

Features

Back plunger type dial gauges are suitable for mounting onto leveling machine tool tables or inspection jigs, and for use in small spaces where the graduations of standard dial gauges are difficult to see.
Models 2960T, 2961T, 2990T-10 and 2991T-10, which use Mitutoyo’s proprietary shock-proofing mechanism, have excellent durability and shock resistance.
Model 2990T-10 provides 0.001mm graduation.

Additional information

Weight N/A
Dimensions N/A
Item Type

Inch, Metric

Graduation

.0001in, .0005in, 0.001mm, 0.01mm

Range

.008in/.01in, .04in/.05in, 0.1mm/0.14mm, 1mm/1.27mm

Dial Reading

4-0-4, 20-0-20, 50-0-50

Accuracy

.0002in, .0005in, 0.0065mm, 0.014mm

Force

0.4-1.5N, 0.4-1.4N

Remarks

One revolution type / Shockproof / Jeweled bearings, One revolution type / Shockproof
