ABSOLUTE Digimatic Indicator ID-U – Series 575 – with Slim and Simple Design

$180.90

Slim type digital indicator with low price.
Large LCD and simple key operation.
After the initial origin setting, the ID-U no longer needs absolute positioning over the entire battery life; the origin is remembered even after power-off.
Ideal for installation into measuring devices because of it’s compact design and long battery life.
Employing the ABSOLUTE linear encoder, the ID-U always displays the spindle “Absolute Position” from the origin at power-on. Also unlimited response speed eliminates over-speed errors.
Flat back type only no option for backs.
SPC data output.

Clear
Qty:
SKU: N/A Category:

Description

SKUItem TypeModel NoRangeAccuracyLCD ResolutionMeasuring ForceStem DiameterRemarksPriceBuyhf:att:pa_item-typehf:att:pa_color
575-122Inch/MetricID-U1025M0-1in 0-25.4mm.0008in.0005in 0.01mm1.8N or less5/16inM2.5x0.45 Thread ISO/JIS type$180.90
Qty:
inch-metric
575-123Inch/MetricID-U1025E0-1in 0-25.4mm.0008in.0005in 0.01mm1.8N or less3/8inNo.4-48 UNF Thread ANSI/AGD type$180.90
Qty:
inch-metric
575-121MetricID-U10250-25.4mm0.02mm0.01mm1.8N or lessØ8mmM2.5x0.45 Thread ISO/JIS type$180.90
Qty:
metric

Optional Accessories

SKUDescriptionPriceBuyhf:att:pa_colorhf:att:pa_item-type
540774Spindle lifting cable (stroke: .4” / 10mm)$29.68
Qty:
905338SPC cable (40"/1m)$36.05
Qty:
905409SPC cable (80"/2m)$42.98
Qty:

Features

Slim type digital indicator with low price.
Large LCD and simple key operation.
After the initial origin setting, the ID-U no longer needs absolute positioning over the entire battery life; the origin is remembered even after power-off.
Ideal for installation into measuring devices because of it’s compact design and long battery life.
Employing the ABSOLUTE linear encoder, the ID-U always displays the spindle “Absolute Position” from the origin at power-on. Also unlimited response speed eliminates over-speed errors.
Flat back type only no option for backs.
SPC data output.

Technical Data

Accuracy: Refer to the list of specifications.
Resolution: 0.01mm or .0005″/0.01mm
Display: LCD
Length standard: ABSOLUTE electrostatic capacitance type linear encoder
Max. response speed: Unlimited
Measuring force: Refer to the list of specifications
Battery: SR44 (1 pc.), 938882
Battery life: Approx. 20,000 hours under normal use
Dust/Water protection level: IP42

Function

Origin-set, Zeroset, Counting direction switching, Power ON/OFF, Data output, inch/mm conversion
(on inch/metric models only)
Alarm: Low voltage, Counting value composition error, Over-flow error

Optional Accessories

905338: SPC cable (40” / 1m)
905409: SPC cable (80” / 2m)
540774: Spindle lifting cable (stroke: .4” / 10mm)

Additional information

Weight N/A
Dimensions N/A
Item Type

Inch/Metric, Metric

Model No.

ID-U1025M, ID-U1025E, ID-U1025

Range

0-1in 0-25.4mm, 0-25.4mm

LCD Resolution

.0005in 0.01mm, 0.01mm

Accuracy

.0008in, 0.02mm

Measuring Force

1.8N or less

Stem Dia.

5/16in, 3/8in, Ø8mm

Remarks

M2.5×0.45 Thread ISO/JIS type, No.4-48 UNF Thread ANSI/AGD type
