ABSOLUTE Low Force Caliper Series 573

$760.50

Due to the low measuring force these calipers are ideal for elastic or resilient work pieces such as plastic parts and rubber parts that standard calipers cannot measure. With SPC data output. Supplied in fitted plastic case.

Clear
Qty:
SKU: N/A Category:

Description

SKUTypeRangeLCD ResolutionAccuracyMass (g)PriceBuy
573-191-30Metric0-180mm0.01mm0.05mm253$760.50
Qty:
573-291-30Inch/Metric0-7in 0-180mm.0005in 0.01mm.002in253$760.50
Qty:

Optional Accessories

SKUDescriptionPriceBuy
959143Data hold unit (SPC output model only)$19.49
Qty:
959149SPC cable with data switch (1m / 40”)$44.33
Qty:
959150SPC cable with data switch (2m / 80”)$49.68
Qty:

Features

Due to the low measuring force these calipers are ideal for elastic or resilient work pieces such as plastic parts and rubber parts that standard calipers cannot measure. With SPC data output. Supplied in fitted plastic case.

Technical Data

Accuracy: Refer to the list of specifications.
Resolution: 0.01mm or .0005″/0.01mm
Display: LCD
Length standard: ABSOLUTE electrostatic capacitance type linear encoder
Measuring force: 0.49N to 0.98N (50gf to 100gf)
Jaw retraction: 0.3mm
Max. response speed: Unlimited
Battery: SR44 (1 pc.), 938882
Battery life: Approx. 3.5 years under normal use

Optional Accessories

959143: Data hold unit
959149: SPC cable with data switch (40” / 1m)
959150: SPC cable with data switch (80” / 2m)

Additional information

Weight N/A
Dimensions N/A
Item Type

Inch/Metric, Metric

Range

0-7in 0-180mm, 0-180mm

LCD Resolution

.0005in 0.01mm, 0.01mm

Accuracy

.002in, 0.05mm

Mass (g)

253
