ABSOLUTE Digimatic Indicator ID-N/B – Series 543 – with Dust/Water Protection Conforming to IP66

Starting at $334.80

Proven ABSOLUTE sensor.
Rated to IP66 water- and dust-proofing standard and oil resistance improved.
Slim body design is advantageous for multi-point measurements.
Improvement in workability with the LCD readout-rotation function.
Back plunger design (ID-B).
Built-in tolerance judgment function.
Switchable resolution.
Waterproof data output connector.
Built-in hold/preset function

Clear
Qty:
SKU: N/A Category:

Description

SKUItem TypeModel No.RangeAccuracyLCD ResolutionMeasuring ForcePriceBuyhf:att:pa_item-typehf:att:pa_color
543-571Inch/MetricID-N1012E.5in 12.7mm.0008in 0.02mm.0008in 0.02mm2.0N or less$334.80
Qty:
inch-metric
543-576Inch/MetricID-N112E.5in 12.7mm.00012in 0.003mm.00012in 0.003mm2.0N or less$463.50
Qty:
inch-metric
543-581Inch/MetricID-B1005E.22in 5.6mm.0008in 0.02mm.0005in 0.01mm2.0N or less$369.00
Qty:
inch-metric
543-586Inch/MetricID-B105E.22in 5.6mm.00012in 0.003mm.0005/.00005in 0.01/0.001mm2.0N or less$498.60
Qty:
inch-metric
543-570MetricID-N10125.0mm0.02mm0.01mm2.0N or less$334.80
Qty:
metric
543-575MetricID-N1125.0mm0.003mm0.001/0.01mm2.0N or less$463.50
Qty:
metric
543-580MetricID-B10055.0mm0.02mm0.01mm2.0N or less$369.00
Qty:
metric
543-585MetricID-B1055.0mm0.003mm0.001mm2.0N or less$498.60
Qty:
metric

Optional Accessories

SKUDescriptionPriceBuyhf:att:pa_colorhf:att:pa_item-type
21EZA145Lug (for JIS/ISO model)$14.67
Qty:
21EZA146Lug (for AGD model)$14.67
Qty:
02ACA376Rubber boot (for ID-N, NBR)$5.31
Qty:
238774Rubber boot (for ID-N, silicon)$12.65
Qty:
21EAA212Rubber boot (for ID-B, silicon)$8.51
Qty:
21EAA194SPC cable (40” / 1m)$37.80
Qty:
21EAA190SPC cable (80” / 2m)$51.57
Qty:
21EAA210Bifurcated connecting cable with zero-setting terminal (40”/1m)$99.00
Qty:
21EAA211Bifurcated connecting cable with zero-setting terminal (80”/2m)$105.30
Qty:
125317Spare rubber boot (for dust-proof type)$4.14
Qty:
21EZA105Lifting knob (mm)$20.61
Qty:
21EZA150Lifting knob (inch)$20.61
Qty:

Features

Proven ABSOLUTE sensor.
Rated to IP66 water- and dust-proofing standard and oil resistance improved.
Slim body design is advantageous for multi-point measurements.
Improvement in workability with the LCD readout-rotation function.
Back plunger design (ID-B).
Built-in tolerance judgment function.
Switchable resolution.
Waterproof data output connector.
Built-in hold/preset function

Technical Data

Resolution: 0.01mm, 0.01mm/0.001mm, .0005”/0.01mm
or .0005”/.00005”/0.01mm/0.001mm
Display: LCD
Length standard: ABSOLUTE electrostatic capacitance type
linear encoder
Max. response speed: Unlimited
Measuring force: 2.5N (2.0N: Back plunger type)
Battery: SR44 (1 pc.), 938882
Battery life: Approx. 7000 hours under normal use
Dust/Water protection level: IP66

Function

Zero-setting, Presetting, Direction switching, Tolerance
judgment, Display hold, Data output,
inch/mm conversion (on inch/metric models only)
Alarm: Low voltage, Counting value composition error,
Over-flow error, Tolerance limit setting error

Optional Accessories

21EZA105: Lifting knob (for ISO/JIS model)
21EZA150: Lifting knob (for AGD model)
21EZA145: Lug (for JIS/ISO model)
21EZA146: Lug (for AGD model)
02ACA376: Rubber boot (for ID-N, NBR)
238774: Rubber boot (for ID-N, silicon)
125317: Rubber boot (for ID-B, NBR)
21EAA212: Rubber boot (for ID-B, silicon)
21EAA194: SPC cable (40” / 1m)
21EAA190: SPC cable (80” / 2m)
21EAA210: Bifurcated connecting cable with zero-setting terminal (40”/1m)
21EAA211: Bifurcated connecting cable with zero-setting terminal (80”/2m)

Additional information

Weight N/A
Dimensions N/A
Item Type

Inch/Metric, Metric

Model No.

ID-N1012E, ID-N112E, ID-B1005E, ID-B105E, ID-N1012, ID-N112, ID-B1005, ID-B105

LCD Resolution

.0008in 0.02mm, .00012in 0.003mm, .0005in 0.01mm, .0005/.00005in 0.01/0.001mm, 0.01mm, 0.001/0.01mm, 0.001mm

Range

.5in 12.7mm, .22in 5.6mm, 5.0mm

Accuracy

.0008in 0.02mm, .00012in 0.003mm, 0.02mm, 0.003mm

Measuring Force

2.0N or less
