ABSOLUTE Digimatic Indicator ID-S – Series 543 – with Simple Design

Starting at $163.80

After the initial zero-setting with the Origin button, the repeated absolute positioning is no longer necessary over entire batterylife.
Unlimited response speed eliminates overspeed errors
Similar in size to standard Series 2 dial indicators.
SPC data output.

Clear
Qty:
SKU: N/A Category:

Description

SKUItem TypeModel NoLCD ResolutionRangeAccuracyStem DIAForceContact PointPriceBuyhf:att:pa_item-typehf:att:pa_color
543-782Inch/MetricID-S1012MX.0005in 0.01mm.5in 12.7mm.0008in5/16in2.0N or lessM2.5x0.45 Thread$163.80
Qty:
inch-metric
543-782BInch/MetricID-S1012MBX.0005in 0.01mm.5in 12.7mm.0008in5/16in2.0N or lessM2.5x0.45 Thread$163.80
Qty:
inch-metric
543-783Inch/MetricID-S1012E.0005in 0.01mm.5in 12.7mm.0008in3/8in2.0N or less4-48 UNF Thread$163.80
Qty:
inch-metric
543-783BInch/MetricID-S1012EB.0005in 0.01mm.5in 12.7mm.0008in3/8in2.0N or less4-48 UNF Thread$163.80
Qty:
inch-metric
543-791Inch/MetricID-S112MX.0005in 0.01mm.5in 12.7mm.0001in5/16in2.0N or lessM2.5x0.45 Thread$261.00
Qty:
inch-metric
543-791BInch/MetricID-S112MBX.0005in 0.01mm.5in 12.7mm.0001in5/16in2.0N or lessM2.5x0.45 Thread$261.00
Qty:
inch-metric
543-792Inch/MetricID-S112EX.0005in 0.01mm.5in 12.7mm.0001in3/8in2.0N or less4-48 UNF Thread$252.90
Qty:
inch-metric
543-792BInch/MetricID-S112EBX.0005in 0.01mm.5in 12.7mm.0001in3/8in2.0N or less4-48 UNF Thread$252.90
Qty:
inch-metric
543-793Inch/MetricID-S112TX.0001in 0.001mm.5in 12.7mm.0001in3/8in2.0N or less4-48 UNF Thread$252.90
Qty:
inch-metric
543-793BInch/MetricID-S112TBX.0001in 0.001mm.5in 12.7mm.0001in3/8in2.0N or less4-48 UNF Thread$252.90
Qty:
inch-metric
543-795Inch/MetricID-S112PMX.0005in 0.01mm.5in 12.7mm.0001in5/16in2.5N or lessM2.5x0.45 Thread$287.10
Qty:
inch-metric
543-795BInch/MetricID-S112PMBX.0005in 0.01mm.5in 12.7mm.0001in5/16in2.5N or lessM2.5x0.45 Thread$287.10
Qty:
inch-metric
543-796Inch/MetricID-S112PEX.0005in 0.01mm.5in 12.7mm.0001in3/8in2.5N or less4-48 UNF Thread$279.00
Qty:
inch-metric
543-796BInch/MetricID-S112PEBX.0005in 0.01mm.5in 12.7mm.0001in3/8in2.5N or less4-48 UNF Thread$279.00
Qty:
inch-metric

Optional Accessories

SKUDescriptionPriceBuyhf:att:pa_colorhf:att:pa_item-type
21EZA198Spindle lifting lever (ISO/JIS type)$5.31
Qty:
21EZA199Spindle lifting lever (ANSI/AGD type)$4.86
Qty:
540774Spindle lifting cable (stroke: .4” / 10mm)$29.68
Qty:
125317Spare rubber boot (for dust-proof type)$4.14
Qty:
21EZA105Lifting knob (mm)$20.61
Qty:
21EZA150Lifting knob (inch)$20.61
Qty:
905338SPC cable (40"/1m)$36.05
Qty:
905409SPC cable (80"/2m)$42.98
Qty:

Features

After the initial zero-setting with the Origin button, the repeated absolute positioning is no longer necessary over entire batterylife.
Unlimited response speed eliminates overspeed errors
Similar in size to standard Series 2 dial indicators.
SPC data output.

Technical Data

Accuracy: Refer to the list of specifications
Resolution: 0.01mm, 0.001mm, .0005″/0.01mm .0001”/0.001mm or .00005”/0.001mm
Display: LCD
Length standard: ABSOLUTE electrostatic capacitance-type linear encoder
Max. response speed: Unlimited
Measuring force: Refer to the list of specifications
Battery: SR44 (1 pc.) 938882
Battery life: Approx. 20,000 hours under normal use
Dust/Water protection level: IP42 (IP53: 543-794B,543-795B, 543-796B)
Inspection certificate is included.

Function

Origin-set, Zeroset, Counting direction switching, Power ON/OFF, Data output,
inch/mm conversion (on inch/metric models only)
Alarm: Low voltage, Counting value composition error,Over-flow error

Optional Accessories

905338: SPC cable (40”/1m)
905409: SPC cable (80”/2m)
21EZA198: Spindle lifting lever (ISO/JIS type)
21EZA199: Spindle lifting lever (ANSI/AGD type)
540774: Spindle lifting cable (stroke: .4” / 10mm)
21EZA105 Lifting knob (mm)
21EZA150 Lifting knob (inch)
125317: Spare rubber boot (for dust-proof type)

Additional information

Weight N/A
Dimensions N/A
Item Type

Inch/Metric

Model No.

ID-S1012MX, ID-S1012MBX, ID-S1012E, ID-S1012EB, ID-S112MX, ID-S112MBX, ID-S112EX, ID-S112EBX, ID-S112TX, ID-S112TBX, ID-S112PMX, ID-S112PMBX, ID-S112PEX, ID-S112PEBX

LCD Resolution

.0001in 0.001mm, .0005in 0.01mm

Range

.5in 12.7mm

Accuracy

.0001in, .0008in

Stem DIA

3/8in, 5/16in

Force

2.0N or less, 2.5N or less

Contact Point

M2.5×0.45 Thread, 4-48 UNF Thread
