Blade Type Caliper – Series 573, 536 – ABSOLUTE Digimatic and Vernier Type

Starting at $352.80

The thin blade type jaws fit into very small grooves and making previously difficult outside measurements far easier to obtain.
The OD measuring faces are carbide-tipped.
With depth bar.
With SPC data output. (Series 573)
Supplied in fitted plastic case.

Clear
Qty:
SKU: N/A Category:

Description

SKUItem TypeRangeAccuracyLCD ResolutionGraduationMassPriceBuyhf:att:pa_item-typehf:att:pa_color
573-734Inch/Metric0-6in 0-150mm.001in.0005in 0.01mm-168g$532.80
Qty:
inch-metric
536-134Metric0-150mm0.05mm-0.05mm130g$352.80
Qty:
metric
536-135Metric0-200mm0.05mm-0.05mm160g$389.70
Qty:
metric
536-136Metric0-300mm0.08mm-0.05mm340g$414.00
Qty:
metric
573-634-20Metric0-150mm0.02mm0.01mm-168g$532.80
Qty:
metric

Optional Accessories for Digital Model

SKUDescriptionPriceBuyhf:att:pa_colorhf:att:pa_item-type
05CZA624SPC cable with data switch (1m / 40”)$84.51
Qty:
05CZA625SPC cable with data switch (2m / 80”)$85.82
Qty:

Features

The thin blade type jaws fit into very small grooves and making previously difficult outside measurements far easier to obtain.
The OD measuring faces are carbide-tipped.
With depth bar.
With SPC data output. (Series 573)
Supplied in fitted plastic case.

Technical Data

Accuracy: Refer to the list of specifications. (excluding quantizing error for digital models)
Resolution*: 0.01mm or .0005″/0.01mm
Graduation**: 0.05mm
Display*: LCD
Length standard*: ABSOLUTE electrostatic capacitance type linear encoder
Max. response speed*: Unlimited
Battery*: SR44 (1 pc.), 938882
Battery life*: Approx. 3.5 years under normal use
*Digital models **Analog models

Optional Accessories for Digital Model

05CZA624: SPC cable with data switch (1m / 40”)
05CZA625: SPC cable with data switch (2m / 80”)

Additional information

Weight N/A
Dimensions N/A
Item Type

Inch/Metric, Metric

Range

0-6in 0-150mm, 0-150mm, 0-200mm, 0-300mm

Accuracy

.001in, 0.05mm, 0.08mm, 0.02mm

LCD Resolution

-, .0005in 0.01mm, 0.01mm

Graduation

-, 0.05mm

Mass

130g, 168g, 160g, 340g
