Bore Gauges Series 526 – for Extra Small Holes

Starting at $388.80

These Bore Gages measure diameters of small holes. The radial displacement of split-ball contact is converted to axial displacement of measuring rod, which is shown on the dial indicator.

Clear
Qty:
SKU: N/A Category:

Description

SKUItem TypeRangeRemarksAnvilsNeedlesProbe DepthPriceBuyhf:att:pa_item-typehf:att:pa_color
526-175-11Inch.037-.061inWithout dial gauge51.45in$2,034.00
Qty:
inch
526-155-11Inch.145-.29inWithout dial gauge711.26in$1,845.00
Qty:
inch
526-176-11Inch.037-.061inWith 2923SB-10 / Graduation.0001in51.45in$2,178.00
Qty:
inch
526-166-11Inch.06-.157inWith 2923SB-10 / Graduation.0001in92.68,.89in$3,150.00
Qty:
inch
526-156-11Inch.145-.29inWith 2923SB-10 / Graduation.0001in711.26in$1,989.00
Qty:
inch
526-170-11Metric0.95-1.55mmWithout dial gauge6111.5mm$2,034.00
Qty:
metric
526-160Metric1.5-4mmWithout dial gauge9217.5,22.5mm$3,105.00
Qty:
metric
526-173-11Metric0.95-1.55mmWith 2046SB / Graduation 0.01mm6111.5mm$2,124.00
Qty:
metric
526-153-11Metric3.7-7.3mmWith 2046SB / Graduation 0.01mm7132mm$1,944.00
Qty:
metric
526-126Metric7-10mmWith 2046SB / Graduation 0.01mm6156mm$427.50
Qty:
metric
526-127Metric10-18mmWith 2046SB / Graduation 0.01mm8162mm$388.80
Qty:
metric
526-172-11Metric0.95-1.55mmWith 2019SB-10 / Graduation 0.001mm6111.5mm$2,223.00
Qty:
metric
526-162Metric1.5-4mmWith 2019SB-10 / Graduation 0.001mm9217.5,22.5mm$3,447.00
Qty:
metric
526-152-11Metric3.7-7.3mmWith 2019SB-10 / Graduation 0.001mm7132mm$2,034.00
Qty:
metric
526-124Metric7-10mmWith 2019SB-10 / Graduation 0.001mm6156mm$480.60
Qty:
metric
526-125Metric10-18mmWith 2019SB-10 / Graduation 0.001mm8162mm$443.70
Qty:
metric

Optional Accessories

SKUDescriptionPriceBuy
215-120-10Bore Gauge Stand$1,278.00
Qty:

Features

These Bore Gages measure diameters of small holes. The radial displacement of split-ball contact is converted to axial displacement of measuring rod, which is shown on the dial indicator.

Technical Data

Accuracy:4µm/.00016”
Indication stability:2µm/.00008”
Graduation:0.01mm,0.001mm, .0005 or.00001″

Optional Accessory

215-120-10 Bore gauge stand.

Additional information

Weight N/A
Dimensions N/A
Item Type

Inch, Metric

Range

.037-.061in, .145-.29in, .06-.157in, 0.95-1.55mm, 1.5-4mm, 3.7-7.3mm, 7-10mm, 10-18mm

Remarks

Without dial gauge, With 2923SB-10 / Graduation.0001in, With 2046SB / Graduation 0.01mm, With 2019SB-10 / Graduation 0.001mm

Anvils

5, 6, 7, 8, 9

Needles

1, 2

Probe Depth

.45in, 1.26in, .68,.89in, 11.5mm, 17.5,22.5mm, 32mm, 56mm, 62mm
