Digital Outside Micrometers – Series 193

Starting at $163.80

Mechanical digit counter with 0.01mm or .001″ reading for quick and error-free reading
With a standard bar except for 0-25mm / 0 -1” model.

Clear
Qty:

Description

SKUItem TypeRangeAccuracyRemarksDisplayPriceBuyhf:att:pa_item-typehf:att:pa_color
193-211Inch0-1in±.0001inwith Friction Thimble.0001 reading is obtained with vernier$172.80
Qty:
inch
193-212Inch1-2in±.0001inwith Standard, Friction Thimble.0001 reading is obtained with vernier$203.40
Qty:
inch
193-213Inch2-3in±.0001inwith Ratchet Stop.0001 reading is obtained with vernier$226.80
Qty:
inch
193-214Inch3-4in±.00015inwith Ratchet Stop.0001 reading is obtained with vernier$251.10
Qty:
inch
193-101Metric0-25mm±2µmwith Ratchet Stop-$163.80
Qty:
metric
193-102Metric25-50mm±2µmwith Ratchet Stop-$184.50
Qty:
metric
193-103Metric50-75mm±2µmwith Ratchet Stop-$221.40
Qty:
metric
193-104Metric75-100mm±2µmwith Ratchet Stop-$247.50
Qty:
metric
193-111Metric0-25mm±2µmwith Ratchet Stop-$172.80
Qty:
metric
193-112Metric25-50mm±2µmwith Ratchet Stop-$203.40
Qty:
metric
193-113Metric50-75mm±2µmwith Ratchet Stop-$226.80
Qty:
metric
193-114Metric75-100mm±3µmwith Ratchet Stop-$251.10
Qty:
metric

Sets

SKUItem TypeRangeIncludesPriceBuyhf:att:pa_item-typehf:att:pa_color
193-923Inch Set0-3in193-211,193-212,193-213$603.00
Qty:
inch-set
193-901Metric Set0-75mm193-101,193-102,193-103$578.70
Qty:
metric-set
193-902Metric Set0-100mm193-101,193-102,193-103,193-104$741.60
Qty:
metric-set

Features

Mechanical digit counter with 0.01mm or .001″ reading for quick and error-free reading
With a standard bar except for 0-25mm / 0 -1” model.

Technical Data

Accuracy: Refer to the list of specifications.
Counter reading: 0.01mm or .001″
Graduation: 0.01mm, 0.001mm, .001″ or .0001″
Flatness: 0.6ìm / .000024”
Parallelism: (2+R/100)µm, R=max. range (mm)
[.00008” + .00004” (L/4)]”, L= max. range (inch)
Measuring faces: Carbide tipped

Additional information

Weight N/A
Dimensions N/A
Item Type

Inch, Metric

Range

0-1in, 1-2in, 2-3in, 3-4in, 0-25mm, 25-50mm, 50-75mm, 75-100mm

Accuracy

±.0001in, ±.00015in, ±2µm, ±3µm

Remarks

with Friction Thimble, with Standard, Friction Thimble, with Ratchet Stop

Display

-, .0001 reading is obtained with vernier
