Indicating Micrometer – Series 510

Starting at $785.70

Retractable anvil with indicator for threewire measurements of pitch diameter of precision screws, and parallelism measurements.
With a standard bar except for 0-25mm /0-1″ model.
IP protection level: 54
Supplied in fitted plastic case.

Clear
Qty:
SKU: N/A Category:

Description

SKUItem TypeRangeIndicating RangeRemarksPriceBuyhf:att:pa_item-typehf:att:pa_color
510-132Inch1-2in0-.0023in-$846.00
Qty:
inch
510-131Inch0-1in0-.0023in-$785.70
Qty:
inch
510-133Inch2-3in0-.0023in-$945.00
Qty:
inch
510-134Inch3-4in0-.0023in-$1,026.00
Qty:
inch
510-151Inch0-1in0-.0023inRetractable anvil button on left side$785.70
Qty:
inch
510-121Metric0-25mm0-0.060mm-$785.70
Qty:
metric
510-122Metric25-50mm0-0.060mm-$865.80
Qty:
metric
510-123Metric50-75mm0-0.060mm-$972.00
Qty:
metric
510-124Metric75-100mm0-0.060mm-$1,044.00
Qty:
metric
510-141Metric0-25mm0-0.060mmRetractable anvil button on left side$785.70
Qty:
metric

Optional Accessories

SKUDescriptionPriceBuyhf:att:pa_colorhf:att:pa_item-type
04AZA12416mm / .63" workpiece stopper (not available for 25mm / 1"" model)"$14.00
Qty:
04AZA12514mm / .55" workpiece stopper"$14.00
Qty:
04AZA12614mm / .55" workpiece stopper"$14.00
Qty:

Features

Retractable anvil with indicator for threewire measurements of pitch diameter of precision screws, and parallelism measurements.
With a standard bar except for 0-25mm /0-1″ model.
IP protection level: 54
Supplied in fitted plastic case.

Technical Data

Spindle feed error: 3µm/ .00012″
Dial indication accuracy: 1µm / .00004″
Dispersion of indication: 0.4µm/ .00002″
Graduation: 0.001mm or .0001″
Dial reading: 0.001mm or .00005″
Flatness: 0.3µm/ .000012″
Parallelism: 0.6µm/ .000024″ for models up to 50mm / 2″
1µm/ .00004″ for models over 50mm / 2″
Measuring force: 5-10N (500 – 1000gf)
Measuring faces: Carbide tipped

Optional Accessories

04AZA124: 16mm / .63″ workpiece stopper (not available for 25mm / 1″ model)
04AZA125: 14mm / .55″ workpiece stopper
04AZA126: 14mm / .55″ workpiece stopper

Additional information

Weight N/A
Dimensions N/A
Item Type

Inch, Metric

Range

0-1in, 1-2in, 2-3in, 3-4in, 0-25mm, 25-50mm, 50-75mm, 75-100mm

Indicating Range

0-.0023in, 0-0.060mm

Remarks

-, Retractable anvil button on left side
