Digimatic Caliper Gauges – Series 209 – External Tube Thickness Measurement Type

Starting at $662.40

Versatile OD measuring gauges for groove thickness, tube thickness, and hard-to-reach dimensions. The Digimatic Caliper Gauges provide error-free LCD readings as well as data output for SPC analysis.

Clear
Qty:
SKU: N/A Category:

Description

SKUItem TypeRangeAccuracyLCD ResolutionMax. Measuring Depth (L)Measuring Contact Type / Set Up TypeMeasuring Contact Length (Hb)Measuring Contact Length (Hf)MassPriceBuyhf:att:pa_item-typehf:att:pa_color
209-570Inch/Metric0-.39in 0-10mm.0008in 0.05mm.0002in 0.0005mm1.37in 35mmBall .059in/ 1.5mm dia. Both/ A.75in 19.1mm.73in 18.6mm240g$662.40
Qty:
inch-metric
209-571Inch/Metric0-.39in 0-10mm.0004in 0.01mm.0002in 0.0005mm1.37in 35mmDisc .24in/ 6mm dia. Both / C.85in 21.7mm.58in 14.8mm175g$662.40
Qty:
inch-metric
209-572Inch/Metric0-.78in 0-20mm.001in 0.02mm.0005in 0.01mm3.2in 85mmBall .059in/ 1.5mm dia. Both/ A.97in 24.7mm.97in 24.6mm280g$662.40
Qty:
inch-metric
209-573Inch/Metric0-.78in 0-20mm.001in 0.02mm.0005in 0.01mm3.2in 80mmBall .059in/ 1.5mm dia. Both/ B.97in 24.7mm.10in 2.5mm270g$662.40
Qty:
inch-metric
209-913Inch/Metric0-1.18in 0-30mm.002in 0.04mm.001in 0.02mm4.5in 114mmBall .12in/ 3mm dia. Both / A1.17in 30mm1.17in 30mm430g$662.40
Qty:
inch-metric
209-914Inch/Metric0-1.18in 0-30mm.002in 0.04mm.001in 0.02mm4.58in 116mmBall .12in/ 3mm dia. Both / B1.17in 30mm.16in 4mm410g$662.40
Qty:
inch-metric
209-915Inch/Metric0-1.18in 0-30mm.002in 0.04mm.001in 0.02mm4.56in 116mmDisc 1.97in/ 50mm dia. Both / D1.42in 36mm.94in 24mm430g$662.40
Qty:
inch-metric
209-918Inch/Metric0-1.97in 0-50mm.002in 0.04mm.001in 0.02mm6.57in 167mmBall .12in/ 3mm dia. Both / A1.17in 30mm1.17in 30mm490g$798.30
Qty:
inch-metric
209-919Inch/Metric0-1.97in 0-50mm.0024in 0.06mm.001in 0.02mm6.57in 167mmBall .12in/ 3mm dia. Both / B1.17in 30mm.18in 4.6mm460g$798.30
Qty:
inch-metric
209-920Inch/Metric0-1.97in 0-50mm.003in 0.08mm.001in 0.02mm6.57in 167mmDisc 1.97in/ 50mm dia. Both / D1.42in 36mm.94in 24mm500g$798.30
Qty:
inch-metric

Optional Accessories

SKUDescriptionPriceBuyhf:att:pa_colorhf:att:pa_item-type
KPL1961-09209 SERIES INTERFACE ADAPTER (FOR SERIAL #'s "I"" & ABOVE)"$82.26
Qty:
KPL8004-50TRIPOD MOUNT M50/E50$90.00
Qty:
937387.SPC cable (1m / 40”)$45.77
Qty:
965013SPC cable (2m / 80”)$54.09
Qty:

Features

Versatile OD measuring gauges for groove thickness, tube thickness, and hard-to-reach dimensions. The Digimatic Caliper Gauges provide error-free LCD readings as well as data output for SPC analysis.

Technical Data

Resolution: .001”, .0005”, or .0002” 0.01mm, 0.02mm, or 0.005mm
Display: Analog / Digital
Power Supply: AAA Battery (2 pcs.)
Battery life: Approx. 350 hours
Measuring Force: 0.8 – 1.7N
Dust/Water protection level: IP67
Provided with inspection certificate.

Function

Zeroset, Preset, Auto power OFF, Inch/Metric conversion,
Data hold, Max/Min value holding, Data output
* Contact type 3, 4 does not have max. min. value hold.

Optional Accessories

KPL1961-09:SPC Adapter
937387:Digimatic cable (1m)
965013: Digimatic cable (2m)
KPL8004-50:Holder for stand

Additional information

Weight N/A
Dimensions N/A
Item Type

Inch/Metric

Range

0-.39in 0-10mm, 0-.78in 0-20mm, 0-1.18in 0-30mm, 0-1.97in 0-50mm

LCD Resolution

.0002in 0.0005mm, .0005in 0.01mm, .001in 0.02mm

Accuracy

.0008in 0.05mm, .0004in 0.01mm, .001in 0.02mm, .002in 0.04mm, .0024in 0.06mm, .003in 0.08mm

Max Measuring Depth

1.37in 35mm, 3.2in 85mm, 3.2in 80mm, 4.5in 114mm, 4.56in 116mm, 4.58in 116mm, 6.57in 167mm

Measuring Contact Type

Ball .059in/ 1.5mm dia. Both/ A, Disc .24in/ 6mm dia. Both / C, Ball .059in/ 1.5mm dia. Both/ B, Ball .12in/ 3mm dia. Both / A, Ball .12in/ 3mm dia. Both / B, Disc 1.97in/ 50mm dia. Both / D

Measuring Contact Length

.75in 19.1mm, .85in 21.7mm, .97in 24.7mm, 1.17in 30mm, 1.42in 36mm

Measuring Contact Length (Hf)

.73in 18.6mm, .58in 14.8mm, .97in 24.6mm, .10in 2.5mm, 1.17in 30mm, .16in 4mm, .94in 24mm, .18in 4.6mm

Mass

240g, 175g, 280g, 270g, 430g, 410g, 490g, 460g, 500g
